EATON PL9-C20-2 Miniature Circuit Breaker
Brand:EATON
Model:PL9-C20-2
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
EATON PL9-C20-2 Miniature Circuit Breaker
Product manual:
EATON PL9-C20-2 Miniature Circuit Breaker
product overview
EATON PL9-C20-2 is a miniature circuit breaker designed specifically for low-voltage AC circuits, belonging to the Eaton PL9 series.
It is mainly used for overload and short circuit protection of circuits, ensuring the safe operation of electrical equipment and circuits.
This circuit breaker adopts a C-type trip curve and is suitable for general lighting, socket, and motor protection,
Widely used in residential, commercial, and industrial fields.
Main technical parameters
Rated current (In): 20 amperes
Number of poles: 2 poles
Rated voltage: 230/400 volts alternating current (AC)
Release characteristics: C-type release curve, instantaneous release, suitable for general loads
Rated short-circuit breaking capacity: usually 6kA or 10kA, please refer to the product specifications for details
Installation method: 35mm standard guide rail installation, easy to install and maintain quickly
Compliant with standards: Compliant with IEC/EN 60898-1 standard, meeting international safety and performance requirements
Environmental adaptability: Wide working temperature range, suitable for various installation environments
Product Features
Efficient protection: able to quickly disconnect overload and short-circuit currents, preventing damage to circuits and equipment.
Compact design: saves distribution box space and facilitates multi module installation.
Easy to operate: The switch handle is intuitive, making it convenient for users to identify the switch status.
Strong stability: High quality manufacturing ensures long-term stable operation.
Multi purpose application: Suitable for various types of loads, including lighting, sockets, and low-power motors.
Application scope
Residential buildings: provide safety protection for household circuits to prevent line overload and short circuit.
Commercial buildings: protect the electrical systems of office buildings, shopping malls, and other places.
Industrial equipment: Ensure the electrical safety of light industry and manufacturing equipment.
Distribution box and control cabinet: used as branch circuit protection modules.
Product details picture:
PL9-C20-2
