EATON PL9-C4-2-DC Circuit Breaker
Brand:EATON
Model:EATON PL9-C4-2-DC
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
EATON PL9-C4-2-DC Circuit Breaker
Product manual:
EATON PL9-C4-2-DC miniature circuit breaker is a modular miniature circuit breaker designed specifically for direct current (DC) applications,
Widely used in DC distribution systems, such as industrial automation, power systems, communication equipment, and new energy systems.
Here are its detailed product information and application areas:
1、 Basic Product Information
Product Model: EATON PL9-C4-2-DC
Type: Miniature Circuit Breaker (MCB)
Current rating: 4A
Voltage level: typically supports up to 220V DC (per pole) or 440V DC (when connected in series with 2 poles)
Release curve: C-type (C Curve, suitable for medium inductive loads)
Installation method: DIN rail installation
Standard certification: Complies with IEC/EN 60947-2 or IEC/EN 60898 (DC version)
2、 Product Features
C-type tripping characteristic: suitable for slight inductive loads such as small DC motors, relay circuits, etc.
High breaking capacity: It has good short-circuit protection capability, commonly 6kA.
Compact structure: suitable for high-density installation in limited space.
3、 Typical application areas
Industrial automation system
PLC control cabinet, sensor power supply circuit, DC relay control circuit
DC drive device, solenoid valve, and branch protection for small loads of motors
Solar Energy and Energy Storage System (Photovoltaic DC System)
Used for photovoltaic combiner boxes, DC distribution cabinets, and energy storage battery pack circuits
Provide branch protection and rapid isolation for DC buses or subsystems
Communication base station and data center
Circuit protection of communication equipment DC power supply system (such as -48V DC)
Branch isolation open circuit between UPS backend or battery pack
Transportation and Rail Transit Equipment
Power supply protection for electric traction system, DC lighting, and electrical control equipment
Suitable for DC power supply scenarios such as subways and trams
DC charging system (EV field)
DC side protection for electric vehicle charging stations, particularly suitable for low-power branches or control circuits
Input/output protection of power module
Product details picture:
EATON PL9-C4-2-DC
