TEL Tokyo Electron 2981-600534-11 Printed Circuit Board

Product manual:

Product model: 2981-600534-11
Manufacturer: Tokyo Electron Ltd

1、 Product Overview:
2981-600534-11 is a specialized printed circuit board module used in Tokyo Electron (TEL) semiconductor equipment.
It is usually integrated into the internal control system or signal processing unit of the device,
Undertake key functions such as signal acquisition, processing, transmission, or control logic implementation.
This type of PCB is usually customized for TEL and has a design that matches its specific model or control architecture.

2、 Possible functional roles (inferred based on TEL device PCB classification):
Due to TEL typically using specific numbers to identify its PCB, 2981-600534-11 may belong to one of the following types:

Type Function Description
The I/O interface board connects external sensors or actuators and performs signal conversion and transmission with the main control unit
The control logic board is responsible for part of the program control logic and works in conjunction with the CPU
Power distribution board distributes/stabilizes the power required by different modules inside the equipment
Communication interface board communicates with fieldbus or other modules (such as RS-232C, CAN, Ethernet, etc.)
The dedicated function processing board handles specific device functions, such as cavity temperature control, pressure signal analysis, motor drive, etc

3、 Applicable equipment field:

TEL ACT series coating and developing equipment

TEL Clean Track series wafer handling and pre-processing equipment

Auxiliary control module in TEL CVD/ALD system

4、 Technical characteristics (universal TEL PCB features, specific model subject to physical object):
Project Content
Multilayer printed circuit board (4-12 layers are common)
Mixing SMD and DIP devices for packaging components
The power supply voltage is usually ± 5V, ± 12V, 24V DC input
Interface connection for flat cable sockets, horn heads, board edge connectors, etc
Manufacturing standards meet the anti-static and anti-interference standards of TEL cleanroom environment

Product details picture:

2981-600534-11
