TEL Tokyo Electron 2L81-050094-V2 Analog Input Electronic Module

Product manual:

The TEL Tokyo Electron 2L81-050094-V2 Analog Input Module is a key electronic module used in TEL equipment for collecting and processing analog signals. It is widely used in sensor data acquisition, process monitoring, and feedback control systems of various semiconductor manufacturing equipment, and is an important hardware component for achieving high-precision process control.

1、 Basic Information
Product Name: Analog Input Electronic Module

Product model: 2L81-050094-V2

Manufacturer: Tokyo Electron Ltd. (TEL)

Function category: Analog signal acquisition module (AI Module)

Application location: In equipment electrical control systems or sensor integration modules

2、 Main functions
Analog signal acquisition

Supports multi-channel analog inputs, such as voltage (0-10V), current (4-20mA), etc.

Receive continuous signals from temperature sensors, pressure sensors, flow meters, position feedback devices, and other equipment.

Signal conversion and conditioning

Convert analog signals into digital signals (A/D conversion) for processing by the control system;

Built in filtering, isolation, and amplification functions improve signal accuracy and stability.

Communication with control system

Transfer the collected process parameters to the main control PLC or embedded controller;

Realize real-time process data feedback and closed-loop control.

Abnormal detection and alarm linkage

Provide signal anomaly detection capabilities, such as wire breakage, over limit, drift, etc;

Support device alarm, automatic protection, and interlocking functions.

Product details picture:

2L81-050094-V2
