Magnetek 53SW2003-0000 AC Drive
Product manual:
1、 Product Overview
Magnetek 53SW2003-0000 is a three-phase AC driver in the VCD-723 series,
Supports 380-460VAC input voltage with a power level of 3HP. It uses PWM (Pulse Width Modulation) technology,
Equipped with programmable logic control function, supporting high-precision speed control and torque regulation, suitable for industrial applications that require high reliability and flexible control.
2、 Technical characteristics
Three phase 380-460V input
3HP output capability
Support PAC graphical programming control
Up to 150% overload capacity (lasting for 60 seconds)
Support local I/O and LAN interfaces
Optional handheld display unit or panel operation unit
Supports multiple control modes such as speed, tension, and positioning
3、 Typical application areas
Material Handling System
Conveyor drive
Elevators, electric stackers
Sorting and diversion device
Packaging and printing equipment
Automatic boxing machine, packaging line drive
Tension control of roll paper and film conveying
Printing machine main transmission and auxiliary transmission control
Textile and paper industry
Winding control system
Warp tension adjustment
Textile machine speed control system
Processing equipment
Extruder, cutting machine, winding machine
Mixing equipment
Industrial drying equipment and conveyors
process control system
Constant pressure and constant flow pump control
Variable frequency operation of industrial fans and water pumps
Feed and discharge control in heat treatment system
OEM specialized equipment
Customized industrial equipment that requires flexible software control
Multi axis synchronous operation system
Small robotic arms or automation subsystems
Product details picture:
53SW2003-0000
