0190-42550 RF Matching Network Device

Model:0190-42550
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

0190-42550 RF Matching Network Device

Product manual:

0190-42550 is an RF Matching Network designed to achieve impedance matching between RF power sources and loads, ensuring efficient and stable transmission of RF energy while reducing reflected power, providing protection for RF sources and process systems.

Main functions

Impedance matching adjustment

By automatically or manually adjusting the matching network, the load impedance is kept consistent with the output impedance of the RF power supply.

Effectively reduce standing wave ratio (VSWR) and improve system stability.

Reflection power suppression

Significantly reduce the power reflected back to the RF source, avoiding protection or damage to the RF generator due to mismatch.

Process stability guarantee

Quickly adjust the matching state when load conditions change (such as plasma state changes) to ensure process consistency.

Industrial grade structural design

Suitable for continuous operation and high-power RF environments, with good heat dissipation and anti-interference capabilities.

Typical application scenarios

Plasma etching and deposition system in semiconductor manufacturing equipment
