1336F-MCB-SP2G Control Interface Module

Model: 1336F-MCB-SP2G
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

1336F-MCB-SP2G Control Interface Module

Product manual:

1336F-MCB-SP2G Control Interface Module
1336F-MCB-SP2G is the main control circuit board designed by Rockwell Allen Bradley specifically for the 1336 PLUS II series frequency converter, and is the core control unit of the frequency converter.
Core features (15 points)
Suitable for 1336 PLUS II series frequency converters, it is a dedicated main control board for A-frame models (0.5-10HP).
Integrated 164989 REV 20 version control interface, stable hardware version.
Support V/F control and vector control to achieve precise adjustment of motor speed and torque.
4-channel LED status indicator lights, real-time monitoring of operation, faults, and communication status.
Analog input: 0-10VDC, 0-20mA, 0-10k Ω, compatible with multiple types.
Analog output: 0-10VDC, 0-20mA, compatible with external instruments and controls.
3 programmable relay outputs (CR1/CR2/CR3), flexible logic configuration.
Supports industrial Ethernet communication such as EtherNet/IP for easy system integration.
Built in multiple protections for overload, overvoltage, overcurrent, and overheating to ensure equipment safety.
Support encoder feedback to achieve high-precision closed-loop speed/position control.
Wide temperature range: -10 ℃ to+50 ℃, suitable for industrial site environment.
Humidity range of 5% -95% (no condensation), able to withstand humid conditions.
Anti vibration and anti impact design, in compliance with industrial grade reliability standards.
Support parameter backup and recovery, simplify debugging and maintenance.
Modular PCB design, supports online replacement, and quickly restores system operation.
Typical Applications
1336 PLUS II inverter main control board fault replacement and spare parts reserve
Variable frequency speed control of industrial motors such as fans, water pumps, and conveyor belts
Industrial transmission systems for processes such as metallurgy, chemical engineering, water treatment, and papermaking
Upgrading and Maintenance of the Old 1336 PLUS II Inverter System
Core control of variable frequency drive unit for factory automation production line
