140CPS11420 power module

Model: 140CPS11420
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

140CPS11420 power module

Product manual:

140CPS11420 power module is an industrial grade power module in Schneider Electric's Modicon series PLC system, used to provide stable DC power for PLC controllers and I/O modules.

Product Overview

Model: 140CPS11420

Type: PLC power module

Purpose: To convert alternating current into direct current, providing stable power to the PLC system and its I/O modules, ensuring reliable operation of the control system.

Main Features

Industrial grade design: sturdy structure, suitable for long-term use in industrial environments

Flexible configuration: can be used independently or in parallel with modules of the same model to improve power supply capacity

Protection function: equipped with overload and overvoltage protection, with power status indication

Compatibility: Compatible with Modicon Quantum PLC series and I/O modules

Technical specifications (typical)

Input voltage: 115V or 230V AC

Output voltage: approximately 5.1V DC

Output current: about 11 A per module, parallel connection can increase it to about 20 A

Rated power: approximately 130   VA

Starting current (surge): approximately 38 A at 115 V, approximately 19 A at 230 V

Working temperature: 0 ° C~60 ° C
