140XBP00400 electric backboard
Model: 140XBP00400
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
140XBP00400 electric backboard
Product manual:
Product Overview
140XBP00400 is a backplane module of Schneider Electric's Modicon Quantum series, used for industrial automation PLC systems. It serves as the physical and electrical connection foundation between the CPU, I/O module, and power module, enabling data bus transmission and power supply between modules.
core functionality
Provide slot interfaces for installing power modules, CPU modules, and I/O modules to achieve electrical connections between modules.
Allocate DC power from the power module to supply power to each inserted module.
As the installation foundation for the internal modules of the control cabinet, it supports modular and scalable system design.
Main specifications
Rack type: Modicon Quantum series backplane
Number of slots: 4, capable of installing power modules, CPU modules, and I/O/communication modules
Compatible modules: Supports Quantum series power supply, CPU, and local/remote I/O modules
Installation method: It can be fixed on the control cabinet panel and secured with screws
Weight: Approximately 0.45 kg
Working temperature: 0 ℃~60 ℃
Protection level: IP20, suitable for general industrial environments
Application scenarios
Suitable for small PLC control cabinets or on-site control stations
Used for distributed I/O nodes to achieve modular combination
Provide communication bus and power support between modules in PLC system
Summary of characteristics
Small, lightweight, space saving
Support system expansion within 4 slots
It does not come with power or control functions and needs to be used in conjunction with a power module and CPU/I/O
Improve wiring clarity and modular maintainability
140XBP00400 Product details picture:
