140XCP51000 controller module

Model: 140XCP51000
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

140XCP51000 controller module

Product manual:

Product Overview

140XCP51000 is a placeholder module (dummy module) in Schneider Electric's Modicon Quantum series PLC system. It is not a CPU module that executes programs or logic control, but is used to fill vacant slots in the PLC backplane to protect the slots and maintain system stability.

core functionality

Slot protection: Fill empty slots without installed functional modules to prevent dust and foreign objects from entering the backplane interface.

Maintain air circulation: Keep the internal air circulation path of the rack intact to avoid local overheating.

Maintain system integrity: Maintain the stability of the backplane structure to ensure the normal operation of other modules.

Main specifications

Applicable rack: Modicon Quantum series standard backplane

Number of slots: single slot, occupying one standard slot

Material: Industrial grade plastic, lightweight and sturdy

Installation method: Insert directly into the backplane slot without electrical connection

Weight: Approximately 0.3-0.5 kg

Working temperature: 0 ℃~60 ℃

Protection level: Suitable for use inside industrial control cabinets

Precautions for use

Not equipped with CPU function, unable to execute programs or logic control.

Only used for placeholder and protection, can be replaced when I/O, communication, or other modules need to be added.

Keep the backplate clean during installation to ensure stable operation of other modules.

summary

THE 140XCP51000 is the placeholder/mute module of Quantum system, mainly used to protect the backplane and unused slots, maintain system structure and stability, without participating in control or communication.
