1746-NR4 resistor analog input

Model:1746-NR4
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

1746-NR4 resistor analog input

Product manual:

1746-NR4 Analog Input Module (Resistance Input) Features

Produced by Allen Bradley and belonging to the SLC 500 series
The type is an analog input module, specifically designed for collecting resistance signals
Provide 4 independent input channels
Supports thermocouples, RTDs (Thermistors), and other resistance sensors
High input accuracy, convenient for precise temperature or pressure measurement
Each channel can be independently configured with a range to improve flexibility
Built in overload and short circuit protection to ensure system safety
Fast response speed, suitable for continuous real-time monitoring
Module with status LED indicator for easy operation and fault monitoring
Installed in a single slot on the SLC 500 rack, occupying minimal space
Communicate directly with the PLC controller without the need for additional interfaces
Support multiple industrial standard resistor signal inputs
Industrial grade design, strong anti-interference ability
Suitable for collecting process variables such as temperature, pressure, and liquid level
Commonly used in automated production lines, heat treatment equipment, and process control systems

Summary:
1746-NR4 is a high-precision analog input module designed specifically for resistance signal acquisition. It can stably and reliably transmit signals from thermal resistors or other resistance sensors in industrial fields to the SLC 500 PLC system, achieving precision process control.
