1768-L43-B memory controller unit

Product manual:

The Allen Bradley 1768-L43-B is a memory controller in the CompactLogix PLC series, primarily used for executing programs, managing data, and processing I/O signals in industrial automation control systems. Here are its main information and application instructions:

Basic Information

Series: Allen Bradley CompactLogix 1768

Model: 1768-L43-B

Type: Memory Controller

CPU functions: execute PLC programs, manage I/O data, process logical operations, timing/counting, communication, etc

Memory capacity: Approximately 1 MB of program storage, capable of handling large-scale control programs

Working voltage: 24 V DC

Features and Functions

Support integration of CompactLogix series I/O modules and communication modules

Built in high-speed processor, suitable for medium-sized automation control systems

Programming and debugging can be done through RSLogix 5000/Studio 5000 software

Supports multiple communication protocols, including EtherNet/IP and DeviceNet (with corresponding modules required)

Built in diagnostic function that can display error status, I/O status, and program execution status

Configurable timer, counter, motion control, and data processing functions

Applicable scenarios

Small and medium-sized automated production lines

Control system for packaging, conveying, and mechanical processing equipment

Industrial environments that require centralized control of I/O, execution of logic control, and communication with the upper computer

Used in conjunction with Allen Bradley CompactLogix I/O series modules

1768-L43-B Product details picture:

1768-L43-B product video
