193X264ABG01 signal isolator

Product manual:

The GE 193X264ABG01 Signal Isolator Board is manufactured by General Electric
A key auxiliary module in the 193X series control system, mainly used to achieve signal isolation, conversion, and protection between different electrical circuits in the control system.
This module is very important in application scenarios such as large-scale industrial automation, generator sets, and DC speed control systems,
Especially suitable for avoiding the influence of ground potential difference and interference signals on control logic.

1、 Product Overview:
Product model: 193X264ABG01

Type: Signal Isolator Board

Series affiliation: GE 193X Control Platform

Main functions: electrical isolation, signal conversion, system protection

2、 Core functions:
Electrical isolation
Isolate the control circuit from the power circuit,
Prevent high voltage or peak interference from entering the control system and protect internal precision components.

signal-conditioning
Convert or match analog input signals (such as 4-20mA or 0-10V),
Adapt it to the input requirements of downstream controllers or drive modules.

Strong anti-interference ability
Especially suitable for situations where EMI (electromagnetic interference) is severe in industrial environments,
Has a good common mode rejection ratio.

Signal amplification and buffering
It has certain amplification and buffering functions to improve signal transmission distance and stability.

System protection function
Once abnormal voltage or grounding circuit current is detected, the signal path can be automatically cut off or an alarm can be issued.

3、 Typical application areas:

Industry application examples
Isolation of power generation and energy turbine control, generator excitation feedback
Isolation processing of speed and current feedback signals for steel metallurgy motors
Chemical automation process variables (such as temperature, pressure) signal conversion and isolation
Multi system collaborative control signal conditioning for cement and papermaking
Railway system track power supply and signal control isolation protection

Product details picture:
