193X267BAG01 regulating board

Product manual:

The GE 193X267BAG01 Regulation Board is a key module in the GE 193X series control system,
Mainly used for regulating, amplifying, filtering, and stabilizing voltage, current, or other analog signals.
This regulating board is widely used in DC drive control systems, power generation systems
Ensure accurate and stable signal processing of each module within the metallurgical and chemical automation system.

1、 Product Overview:
Product model: 193X267BAG01

Type: Regulation Board

Series affiliation: GE 193X Control Platform

Function: Signal conditioning, amplification, stabilization, and filtering

2、 Main functions:

signal amplification
Amplify weak signals to a level suitable for system use, ensuring that the system can accurately respond to input signals.

Filtering and noise suppression
Filter the input signal to remove high-frequency noise and interference,
Ensure the purity and reliability of the signal, especially suitable for industrial environments with high noise levels.

System stability enhancement
By adjusting the stability of signals such as voltage and current,
Prevent system failures or malfunctions caused by unstable signals.

Precise control feedback
Adjust and amplify the feedback signal to ensure that the feedback loop operates smoothly during speed regulation
Stability and response speed in precision control such as excitation.

3、 Application areas:

Industry application scenarios
The power generation industry regulates the output voltage, current, and other signals of generators to ensure stable power supply.
Signal regulation is carried out in the motor drive system of steel metallurgy to ensure the accuracy of motor response.
Chemical automation finely adjusts sensor signals in chemical reaction control.
The matching between rail transit signal regulation and electrical system ensures stable operation of equipment.
The automated production line adjusts various sensor feedback signals to ensure precise control of the production line.

Product details picture:
