193X277ABG01 Coordination Card

Product manual:

GE 193X277ABG01 Coordinating Card
It is an important control module in GE's 193X series industrial automation control system.
This module is mainly used for coordinated control and signal synchronization between multiple subsystems,
It is one of the core communication and management components in high-end automation or distributed control systems.

1、 Product basic information:
Product model: 193X277ABG01

Product Name: Coordinating Board/Card

manufacturer: General Electric (GE)

Product series: 193X series control system

2、 Main functions and features:

Function Description
System coordination is used to control the communication, synchronization, and coordination between multiple control modules and subsystems in a control system.
Signal conversion and management convert, integrate, and distribute control signals to ensure signal consistency between system modules.
The status feedback processing collects the working status information of each module and feeds it back to the central processing unit to support decision-making.
Fault tolerance and switching logic coordinate the execution of automatic or redundant switching logic in the event of partial system failure.
High reliability design suitable for industrial environments, with electrical characteristics of anti-interference and stable operation.
3、 Technical parameters (overview):

Project parameter description
The input voltage is usually the internal logic power supply of the system (such as ± 15V or+5V)
Interface type multi pin slot connector, suitable for GE control rack
Signal type: digital control signal, status feedback signal, synchronization pulse, etc
Fast response time to control signal changes, nanosecond level (depending on system configuration)
Working temperature -20 ℃~+60 ℃
Cooling method: natural convection or cabinet air cooling
Installation method: plug-in card, installed in GE 193X control frame

Product details picture:
