193X526AAG02 DC drive power board

Brand:GE
Model:193X526AAG02
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

193X526AAG02 DC drive power board

Product manual:

GE 193X526AAG02 is a board used for DC drive power supply in the 193X control system, mainly providing stable DC power for servo controllers, speed regulation modules, logic control modules, etc.

Key Function
Provide multiple stable DC output voltages (such as ± 15V,+5V)

Used to support DC driver boards, speed control boards, logic processing boards, etc

Built in voltage regulator, rectifier, and filter

Integrate overcurrent and short-circuit protection circuits to enhance system stability

Plug in card design, convenient for installation, replacement, and system maintenance

Technical specifications and parameters

Parameter Name Typical Value
The input voltage is usually 115V/230V AC (powered by the system bus)
Output voltage+5V, ± 15V DC (common specifications)
The output current capacity depends on the number of circuits, typically ranging from 2 to 5A
Load adjustment rate ≤± 1% (when switching between full load and light load)
Ripple noise ≤ 50mVp-p (5V output)
Cooling method: natural air cooling/external fan assistance
Structural form: Plug in multi-layer PCB with gold finger interface
Protection functions include overvoltage, overcurrent, overtemperature, and short-circuit protection
Application scenarios
DC Motor Drive System Applied to GE

Power supply for servo controllers, speed controllers, and regulators

Suitable for large-scale industrial automation control platforms

Can be used for power upgrade or replacement of GE Mark I/II/IV systems

Compatibility and Alternative Suggestions
Recommended alternative model: 193X526AAG01 (pay attention to whether the voltage and current specifications match)
