193X528ADG-01 circuit board

Brand:GE
Model:193X528ADG-01
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

193X528ADG-01 circuit board

Product manual:

The GE 193X528ADG-01 circuit board is a key module in the GE 193X series automation control system, responsible for providing complex signal processing and control functions.

Main functional features
Multi functional circuit design: integrating multiple circuit functions, including signal processing
Control logic processing, interface adaptation, etc., capable of adapting to various industrial control requirements

High precision signal processing: providing high-precision analog and digital signal processing capabilities,
Ensure the accuracy and reliability of data transmission

Modular design: adopting modular design, easy to integrate or replace with other control system components

Electrical isolation and protection: Built in electrical isolation design,
Effectively reduce the impact of external electromagnetic interference and noise on the system

Flexible adaptability: adaptable to multiple voltage, current, and signal formats,
Compatible with different types of peripheral devices

Technical specifications and parameters

Parameter Name Parameter Description
Input/output interface for analog and digital signal input/output
Input voltage range 5V, 12V, 24V DC
Output voltage range 5V, 12V, 24V DC
The signal isolation method is designed with built-in electrical isolation to reduce interference and noise effects
Working temperature range: 0 ° C to 70 ° C
Current carrying capacity: maximum 50mA per channel (digital interface)
Installation method: Standard plug-in card design
Size based on specific module design specifications
Cooling method: natural convection cooling
application area
Industrial automation control system: This circuit board is used to connect the main controller with external devices,
Ensure stable operation of the system through signal processing and conversion

Energy management system: In the energy production and distribution system,
Used to achieve precise electrical control and load regulation

Production line automation: used for signal processing, data acquisition, and control tasks in production lines,
Ensure coordination between equipment and control system
