193X531ACG01 diagnostic board

Brand:GE
Model:193X531ACG01
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

193X531ACG01 diagnostic board

Product manual:

193X531ACG01 is a diagnostic circuit board in the GE 193X control system,
Mainly used for system operation status monitoring, fault detection, and auxiliary maintenance.
This module is designed to complement GE drive systems and provide signal analysis for technicians
Status display and maintenance support enhance the visualization and maintainability of system operation.

Core functions
Real time collection and display of key operating parameters of the system

Provide diagnostic signal testing points and monitoring interfaces

Support system operation status LED indication (such as power status, fault status)

Assist in identifying potential faults or signal anomalies in the control system

Collaborate with the main control board or other functional modules to enhance system reliability

Technical parameters (reference values)

Parameter item description
Working voltage+15V DC/+24V DC
Functional circuit type logic judgment circuit+LED display unit
Display content status lights (Power, Run, Fault, etc.) or signal indicators
Interface type: slot connection+test point interface
Typical response time<5ms
Industrial environment, temperature range 0 ℃~70 ℃
Installation structure plug-in card, needs to be inserted into GE system host or dedicated motherboard
Typical application scenarios
GE DC speed regulation system status monitoring

Diagnostic panel for industrial motor control system

Electrical control cabinet auxiliary debugging tool

Signal diagnostic support module for on-site testing and maintenance

Usage and maintenance suggestions
Ensure that the interface is secure and reliable during installation to avoid poor contact

Regularly observe the status of indicator lights and promptly record alarm information

During maintenance, analog/digital signal information can be obtained through testing points

If not working for a long time, avoid storing in high humidity and high temperature environments
