193X543ABG02 electric circuit board

Brand:GE
Model:193X543ABG02
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

193X543ABG02 electric circuit board

Product manual:

Technical parameters and functional characteristics
Model: 193X543ABG02

Product type: Motor Control PCB

System adaptation: GE 193X series industrial automation system

Installation method: Standard card insertion installation, connected to the control framework through a gold finger interface

Input signals: analog signals (such as voltage feedback, current feedback), digital logic commands, trigger control signals

Output signal: Control signal output to actuators, drivers, relays, etc

Onboard components: integrated with multiple operational amplifiers, transistors, adjustable potentiometers, capacitors, resistors, and other standing element devices

Adjustment function: Equipped with a potentiometer for adjusting control gain, response time, compensation parameters, etc

Working voltage: usually ± 15V DC, requiring unified power supply from the system

Working temperature range: -20 ℃ to+70 ℃, suitable for industrial site environment

Status display: Some versions come with LED status indicators for easy debugging and operation monitoring

Application scenarios
GE Mark series industrial motor control system (such as Mark II, IV)

Large DC/AC motor drive equipment

Process control industries such as metallurgy, petrochemicals, power plants, water treatment, pulp and paper manufacturing, etc

Used to perform tasks such as motor start stop control, speed regulation, and status feedback processing

It is often used in the replacement or expansion of electric daughter boards in old GE control systems

Installation and usage precautions
Before installation, the system power must be disconnected to avoid short circuits or arcs during plugging and unplugging operations

The board is a static sensitive device, and an anti-static wristband should be worn during operation
