193X543ADG02 relay card
Brand:GE
Model:193X543ADG02
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
193X543ADG02 relay card
Product manual:
Technical parameters and functional characteristics
Product model: 193X543ADG02
Product Name: Relay Card
Function type: Circuit switch control, status switching, alarm output, etc
Number of channels: generally includes 4-8 independently controlled relays (depending on the actual version)
Contact type: normally open (NO)/normally closed (NC) dry contact output
Coil driving voltage: 24V DC or ± 15V DC (powered by the system)
Contact rated load: approximately 1~2A @ 250V AC or 30V DC (depending on relay specifications)
Response time: Typical 10-20ms
Control mode: The onboard logic interface is controlled by the motherboard and triggers actions automatically or through a program
Interface form: Gold finger connector (used for inserting into GE control frame backplane)
Onboard protection circuit: equipped with freewheeling diode, anti reverse protection, voltage clamp and other circuits
Display function: Some versions come with LED indicator lights that reflect the current status of each relay
Working temperature range: -20 ° C~+70 ° C
Size: Standard 193X series control board size, hot swappable or module replaceable
Functional application
Implement logical switch actions in the control system
Control the start stop of motors, fans, pumps, or other executing devices
System alarm linkage triggering (sound and light alarm, power-off protection)
Equipment operation status switching (working/standby/fault)
Isolation contact output for safety control systems
application area
GE Mark series control systems (such as Mark II/IV)
Power plant automation control system
Large motor control cabinet
Automation sites in industries such as papermaking, chemical, and metallurgy
Distribution control, industrial site signal linkage system
Product details picture:
