193X703ADG01 relay board

Brand:GE
Model:193X703ADG01
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

193X703ADG01 relay board

Product manual:

GE 193X703ADG01 Relay Board Technical Description
Product model: 193X703ADG01
Product Name: Relay Board
Manufacturer: General Electric (GE)
Product Series: 193X Control Module Series

1、 Function Description

Remote start stop of electrical equipment;

Alarm signal or interlock logic execution;

Relay output of control instructions;

Feedback the action status to the upper level controller.

2、 Technical parameters (typical)
Project Content Description
Control input digital control signal (from logic board or central controller)
Output method: Multi channel relay dry contact output (normally open/normally closed)
The driving voltage is usually 24VDC or ± 15VDC (depending on the system)
The number of relays is 4-8 (depending on the specific configuration of the sub model)
Installation method: Insert the card and connect it to the 193X backplane with a gold finger
On board components such as small relays, transistors, diodes, current limiting resistors, etc
Size specification standard 193X board size, with front-end gripper

3、 Typical application scenarios
GE DC drive system (such as DC2000);

Mark I~Mark V control system;

Early turbine control and pump station control systems;

Industrial motors, valves, and relay control components;

Used in conjunction with statistical boards (such as ACG04) and interface boards (such as AAG02).

4、 Maintenance suggestions
Regularly check whether the contact resistance of the relay is abnormal;

Check if the control input has reached the coil terminals of each relay;

Avoid relay failure caused by moisture or high temperature environment;

If the relay does not engage or is severely eroded, the entire board should be replaced;

Avoid stacking and contact with static power sources during storage.
