193X713AAG01 Instrument Board

Brand:GE
Model:193X713AAG01
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

193X713AAG01 Instrument Board

Product manual:

Brief introduction
GE 193X713AAG01 is a precision instrument signal processing board in the 193X series, mainly used for signal acquisition, conversion, conditioning and other processing in industrial automation and power plant control systems. It usually serves as an interface layer or measurement layer, providing buffering, isolation, and amplification functions for analog/digital signals.

2、 Core functions

Analog signal processing: Receive input from external sensors and control signals, and perform filtering, amplification, linearization, and other processing.

Isolation protection: With electrical isolation function, it can effectively protect the downstream control module from interference or surge damage.

Interface conversion: It can convert input signal formats (current, voltage, etc.) into standard signals recognized by the system.

Signal conditioning: Supports multiple input channels and can be independently adjusted according to different channel characteristics (such as gain and level).

High precision and strong stability: suitable for industrial applications that require high measurement accuracy and temperature drift control.

3、 Technical parameters (typical values, reference purposes)

Power supply: ± 15V DC (provided by the host)

Input signal: Analog voltage (± 10V), current (4-20mA or 0-20mA)

Output signal: Standardized analog signal (0-10V, 0-5V, 4-20mA)

Number of input channels: Multi channel (usually 4-8 channels, depending on configuration)

Accuracy level: ± 0.1% F.S. (typical)

Response time:<5ms (depending on signal type)

Working temperature: -10 ° C to+60 ° C

Installation method: GE standard 193X plug-in card structure

4、 Application scenarios

Data acquisition in power generation control systems such as thermal power plants, wind power, and gas turbines
