193X726BAG01 Auxiliary Function Board
Brand:GE
Model:193X726BAG01
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
193X726BAG01 Auxiliary Function Board
Product manual:
Brief introduction
GE 193X726BAG01 is an auxiliary functional module of GE General Electric in the 193X control system series. This module is mainly used to perform non main control logic tasks and assist the system in realizing functions such as signal conversion, logic gate control, overvoltage/overcurrent protection, signal isolation and enhancement. Suitable for power plant automation systems, large drive equipment control systems, and process control devices.
2、 Core functional features
Logical auxiliary function: Execute sub logical tasks that are not directly related to the main logic but must participate in the control process (such as reset, delay, trigger, etc.).
Signal conditioning: Amplify, filter, isolate, and process analog signals from sensors or other modules.
Electrical protection function: Built in overcurrent/overvoltage detection and response logic, which can protect downstream modules or sensitive components.
State transition: It can convert analog signals into digital signals or perform threshold judgment and control.
System self diagnostic support: Some models support fault state recognition and output signal feedback.
3、 Technical parameters (standard configuration)
Parameter category description
The power demand is usually+5V DC/± 15V DC (system power supply)
Input signal type: digital/analog (depending on the application point)
Output signal type TTL/relay contact/analog voltage output
Interface Style 193X Series Dedicated Plug in Edge Gold Finger Interface
Installation method: Plug in installation on 193X motherboard or subrack
PCB size standard 193X module size (6U high x 160mm deep)
Response time is usually less than 2ms
Working temperature range -10 ℃ to+60 ℃
Humidity adaptation range 5%~95% (no condensation)
4、 Examples of application scenarios
Protection Logic Assistance in Power Control System
Signal adjustment and buffering in industrial motor or frequency converter control
Auxiliary excitation or protection relay logic of generator set
Logical relay bridging function in large-scale industrial process control systems
Fault isolation and signal reconstruction of industrial control system
