193X728ABG01 isolation module

Product manual:

193X728ABG01 is an industrial control isolation module launched by GE (General Electric), belonging to the 193X control system family, dedicated to providing electrical isolation during analog or digital signal transmission. It is designed to block noise and current surges from high voltage or interference source signal paths, protecting the core logic and processing modules of the control system.

2、 Key functional features
✅ Electrical isolation of input/output circuits: achieving safe isolation of logic control signals, analog signals, or digital trigger signals

✅ Signal relay and buffering: Enhance signal driving capability and improve remote transmission reliability

Eliminating grounding circuit: avoiding interference signals caused by ground potential difference, ensuring measurement and control accuracy

✅ Wide signal compatibility: supports common industrial signal types such as 4-20mA, 0-10V, TTL, etc

✅ Industrial grade anti-interference capability: adaptable to harsh electromagnetic environments and high-power equipment scenarios

3、 Technical specifications and parameters
Project parameter description
Isolation voltage ≥ 1500VAC (input/output/power supply isolation)
Signal type analog (voltage/current), digital signal (TTL/switch quantity)
High impedance input design, suitable for various sensors or signal sources
Output driving capability can drive downstream TTL, PLC, control relays, etc
Working voltage ± 15V DC (powered by 193X control rack)
Response time<1ms (applicable to fast control systems)
Accuracy level ± 0.1% FS (depending on signal type)
Working environment temperature -10 ° C to+60 ° C (industrial grade)
Installation form: plug-in card, compatible with 193X series backplate
Module size GE 193X standard size board

Product details picture:
