1MRK001608-CAr02 Central Controller Module

Brand:ABB
Model:1MRK001608-CAr02
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

1MRK001608-CAr02 Central Controller Module

Product manual:

Product model: 1MRK001608-CAr02
Name: Central Controller Module
Manufacturer: ABB
Belonging system: used in ABB high-end relay protection and substation automation equipment (such as REL/REF/RET series)

1、 Functional positioning
Main control logic center

The module serves as the "central processing unit" of the device, executing core logical operations, control strategies, event judgments, protection actions, etc.

Coordinate communication and data flow

Coordinate the management and communication modules, power modules, I/O modules, etc. to achieve instruction distribution and status summary.

Protection action decision processing

Based on input signals such as current, voltage, frequency, etc., perform rapid determination of overcurrent, differential, low-voltage and other protection strategies.

Event and Record Management

Responsible for recording the status before and after the occurrence of faults, outputting important information such as sequence of events (SOE), fault waveform recording, etc.

2、 Application Fields
Relay protection equipment for high-voltage transmission system

Installed in ABB REL670, REF615, RET670 and other intelligent electronic devices as the main control core module.

Digital Substation System (IEC 61850 Environment)

As a coordination center in the automation control system, it interfaces and links with SCADA, HMI, and communication gateway.

Power grid protection and automatic switching system

Used for managing key operations such as circuit breaker tripping and closing, bus switching, power conversion, etc.

Automatic protection system for power plants and industrial substations

Applied to critical energy and industrial infrastructure sites to ensure system safety and reliable operation.

3、 Product characteristics (typical parameter features)
High speed digital processor or FPGA architecture

Support multiple input signal channels (analog, switch)

Capable of resisting high electromagnetic interference and suitable for power field environments

Logic programming and parameter setting can be performed through configuration tools
