200-560-000-016 200-560-101-015 VM600 Controller Module

Product manual:

VM600 Controller Module Description (200-560-000-016/200-560-101-015)

The VM600 controller module is the core control unit in industrial vibration monitoring and mechanical protection systems, used to receive sensor signals, execute protection logic, and output control instructions. It is the core part of the VM600 system to achieve automatic monitoring and mechanical protection.

1、 Module positioning

Controller module belonging to the rotating machinery monitoring system

As the core control unit of VM600 system, managing vibration and status monitoring

Collaborate with the Mechanical Protection Card (MPC), sensors, and upper monitoring system

Process logic, alarms, and execute output signals

It can be understood as the "brain" of the device, which determines the vibration protection logic and response actions.

2、 Main functions

signal processing

Receive signals from vibration sensors, speed sensors, or displacement sensors

Filter, shape, and process signals

Provide accurate status data for protection logic use

Protect logical execution

Determine equipment vibration, overspeed, or abnormal status based on preset thresholds

Output alarm or shutdown/deceleration control signals

Support multi-channel logic and redundant protection

System Coordination and Communication

Collaborate with MPC mechanical protection card

Exchange status, events, and historical data with the upper monitoring system

Support remote monitoring and configuration

200-560-000-016 200-560-101-015 VM600 Product details picture:

200-560-000-016 200-560-101-015 VM600 product video
