2098-DSD-020X servo driver

Model:2098-DSD-020X
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

2098-DSD-020X servo driver

Product manual:

Introduction to AB 2098-DSD-020X servo drive

2098-DSD-020X is a digital servo drive (Ultra3000-DSD type) in the Allen Bradley Ultra3000 series. This series is known for its high dynamic performance, rich control modes, and good system compatibility, and is widely used in automation equipment.

Product positioning

This driver is mainly used to control small and medium-sized AC servo motors, with precise motion control capabilities, suitable for situations that require high-speed response and high position accuracy.

Main Features

Full digital servo control: fast response, capable of handling precise position, speed, and torque control.

Multiple control modes: supporting multiple modes such as position, speed, torque, command pulse, analog input, etc.

Excellent dynamic performance: The Ultra3000 series features high bandwidth servo circuits, suitable for mechanical equipment with fast start stop and frequent movements.

Rich protection functions: equipped with complete protection mechanisms for overload, overcurrent, overvoltage, encoder abnormality, overheating, etc.

Strong communication capability: Supports common interfaces in industrial control systems, making it easy to integrate with PLCs and motion controllers.

Flexible parameter settings: can be easily configured through software, and debugging is convenient.

Typical technical scope (Ultra3000 DSD series features)

20 represents the drive capacity level, which is typically used for servo motors around 2.0kW.

Standard parameter range reference:

Supporting motor power: approximately 1.5-2.0 kW

Rated output current range: Medium capacity matched with 020 level

Input power supply: AC input

Control mode: position/speed/torque control

Feedback support: Incremental encoder, servo feedback interface

Communication: Supports SERCOS, digital I/O instructions, etc. (depending on the specific version)

Applicable fields

Packaging production equipment
