25C-D017N104 AC Driver

Product manual:

AB 25C-D017N104 AC Driver - Product Introduction

AB 25C-D017N104 is an AC servo/variable frequency drive (AC Drive) in the Rockwell/Allen Bradley PowerFlex series, used to control the speed, torque, and position of three-phase AC motors. Its serial number belongs to the specific configuration model of PowerFlex 527/523/525 series (based on the suffix N104, it can be determined as a commonly used industrial motor control model).

1、 Product positioning

Category: AC Drive/Inverter

Brand Series: Allen Bradley PowerFlex Series

Main functions: speed regulation, start stop control, overload protection, torque control

Typical matching objects: three-phase asynchronous motors or servo grade AC motors in certain situations

2、 Core features (applicable to drives with "D017" gear)
1. Rated output capacity

In the model, "D017" usually represents the output current of 15A level

Used for driving small and medium power motors

(The actual motor matching needs to confirm the voltage level according to the nameplate, usually 380-480V or 200-240V.)

2. Control mode

V/F (constant voltage/constant frequency)

SVC Vector Control

Automatic motor tuning

Capable of precise speed adjustment

3. Built in signal and protection

Overcurrent protection, overload protection

Overvoltage/undervoltage protection

Ground fault detection

thermal protection

Built in parameter storage, replicable parameter configuration

4. Interface and Communication

According to the suffix N104, it usually includes the following capabilities:

Digital input/output

Analog input (voltage/current)

Safe shutdown input (optional)

Basic communication interface compatible with PLC/controller

(The specific communication protocol depends on the actual nameplate configuration, such as Ethernet/DeviceNet/RS485, etc.)

25C-D017N104 Product details picture:

25C-D017N104 product video
