3500/42M 176449-02 Relay Module

Product manual:

3500/42M 176449-02 Relay Module Description

The 3500/42M 176449-02 relay module is a signal execution and control unit in industrial vibration monitoring and mechanical protection systems. It is used to convert the logic output of the controller or protection module into actual electrical actions, achieving equipment alarm, shutdown, or other protection operations.

1、 Module positioning

Relay interface module belonging to Bently 3500 series monitoring system

Installed in the control cabinet or system rack

Collaborate with controllers, processor modules, and power modules

Output system logic signals to actuators, alarm devices, or other control units

It can be understood as: the "executor" of the system, converting logical signals into actual actions.

2、 Core functions

Logic signal output

Receive signals from controllers or protection units

Output relay action to drive external devices

Supports multiple inputs and outputs

Equipment protection and alarm

Trigger protection action when abnormal vibration, overspeed or fault state is detected

Output shutdown, deceleration, or alarm signals

Improve system reliability and security

System feedback and status indication

Provide feedback on relay action status

Support fault diagnosis and system monitoring

Communicate with the upper monitoring system to achieve remote monitoring

3500/42M 176449-02 Product details picture:
