3500/92 136188-01 Ethernet I/O Module

Model: 3500/92 136188-01
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

O Module

Product manual:

Product Overview

3500/92 136188-01 is an Ethernet I/O module in the Bently Nevada 3500 series mechanical condition monitoring system. It is used to transmit monitoring data from the 3500 system to PLC, DCS or monitoring systems through industrial Ethernet or serial communication interfaces, achieving remote data acquisition and system integration.

core functionality

Ethernet communication: Provides industrial Ethernet interfaces to achieve TCP/IP data transmission.

Serial communication: Supports RS-232 or RS-422/RS-485 serial communication for traditional serial data exchange.

Modbus protocol: Supports Modbus RTU (serial) and Modbus TCP/IP (Ethernet), making it easy to integrate with various automation control systems.

Data exchange: Transmit monitoring data such as vibration, temperature, and status alarms from the 3500 system to external control or monitoring systems.

Technical Specifications

Communication interface: Ethernet (RJ45) and serial interface (RS-232/RS-422/RS-485)

Supported protocols: Modbus RTU and Modbus TCP/IP

Power supply: 24V DC, provided by the main module

Working temperature: -30 ℃ to+65 ℃

Installation method: Suitable for 3500 series rack, standard slot installation

Environmental adaptability: Suitable for industrial sites, able to withstand high humidity and temperature changes

Typical Applications

Real time transmission of data from the mechanical condition monitoring system to the central control system

Integrate with PLC or DCS system network to achieve automation control

Support remote monitoring and data collection to achieve system diagnosis and analysis

Precautions for use
