3ASC25H208 DATX100 Pulse Transformer Board

Model: 3ASC25H208 DATX100
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

3ASC25H208 DATX100 Pulse Transformer Board

Product manual:

3ASC25H208 DATX100 pulse transformer board is a circuit board used for electrical isolation and signal conversion in industrial control systems, commonly used in drivers, control units, or inverter devices.

Basic Information
Model: 3ASC25H208
Name: DATX100 Pulse Transformer Board
Type: Pulse Transformer Circuit Board
Purpose: To achieve isolation and level conversion of high-frequency pulse signals
function
Signal isolation: Isolate control signals from the power side or other circuits to improve anti-interference capability
Level conversion: Convert the input pulse signal into a voltage/current suitable for the output terminal
High speed transmission: suitable for high-frequency signals such as PWM and encoder pulses
Protection control board: blocks high voltage impact and grounding interference
Application scenarios
Servo driver or inverter control unit
Motor Gate Pole Drive Circuit
Control system requiring high-speed isolation transmission
Fieldbus isolation interface
feature
Provide high-speed pulse signal isolation and transmission
Protect the control unit from voltage spikes and interference
Support high-frequency signal applications and maintain signal integrity
