3ASC25H219B DATX133 rotor feedback board

Model: 3ASC25H219B DATX133
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

3ASC25H219B DATX133 rotor feedback board

Product manual:

3ASC25H219B DATX133 rotor feedback board is an encoder feedback processing module in industrial drive systems, mainly used to collect motor rotor position and speed signals, and provide them to the control system for closed-loop control.

Basic Information
Model: 3ASC25H219B
Name: DATX133 rotor feedback board
Type: Rotor/Encoder Feedback Signal Processing Board
Power supply: typically 24 VDC
Main functions
Signal acquisition: Receive feedback signals from encoders (such as A/B/Z phases)
Signal processing: shaping, amplifying, and level converting pulse signals
Data output: transmit the processed signal to the main controller
Anti interference: equipped with isolation design to improve signal stability
Technical Features
Supports high-speed pulse input, suitable for high-precision motion control
Provide stable position signal and speed feedback
Modular structure, easy to maintain and replace
Industrial grade design, suitable for complex working conditions
Application scenarios
Servo drive system motor feedback
Variable frequency drive/inverter control system
Automated equipment motion control
Position and velocity detection in closed-loop control system

This module is an important component for achieving high-precision motion control, responsible for accurately feeding back the actual operating status of the motor to the control system.
