5SHY3545L0010 thyristor module

Model:5SHY3545L0010
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

5SHY3545L0010 thyristor module

Product manual:

5SHY3545L0010 is an industrial grade thyristor (SCR) module mainly used in high-power power control applications. It achieves precise control of high-power loads, such as electric heating, rectification, voltage regulation, or motor power regulation, by adjusting the conduction angle of AC or DC current. The module design emphasizes high voltage resistance, high current carrying capacity, and reliability, making it suitable for long-term industrial operation.

Main functions

Power control: Control the AC or DC load power by adjusting the thyristor conduction angle

High current carrying capacity: suitable for high-power industrial equipment

Quick response: achieving precise power regulation and load control

Protection function: equipped with overcurrent, overvoltage, and overtemperature protection to ensure the safety of modules and equipment

Typical application areas

Industrial heating control

Power regulation of electric furnaces, electric heaters, and heat treatment equipment

Control temperature curve to achieve precise heating

Rectification and power conversion

Rectify AC power into DC power to supply DC loads or drive DC motors

Support adjustable voltage output

Motor speed regulation and drive

Control the operating current of high-power AC or DC motors

Realize smooth start-up, speed regulation, and power adjustment

industrial process control

Used for heating, smelting or power control in industries such as chemical, power, metallurgy, etc

Integrate with automation systems to achieve closed-loop control

Core Features

High voltage and high current carrying capacity

Accurate control of AC or DC power

Industrial grade anti-interference and high reliability

Suitable for long-term continuous operation

5SHY3545L0010 Product details picture:
