5SHY4045L0006 3BHB030310R0001 thyristor module

Product manual:

1、 Product Overview
5SHY4045L0006 (ABB order number: 3BHB030310R0001) is a high-performance thyristor module,
Belonging to ABB's high-power semiconductor device series, mainly used in industrial drives, power control systems, and high-voltage converters.
This module has built-in thyristors (SCR) and necessary protection circuits, suitable for rectification and inverter control applications in high voltage and high current environments.

2、 Technical parameters (typical values)
Project parameter values
Model 5SHY4045L0006
Order number 3BHB030310R0001
Type: thyristor module/thyristor
Maximum forward/reverse voltage (Vdrm) 4500V
On state average current (ITAV) 2600A
Control mode phase control/trigger control
Application packaging: high-power module packaging with bolted connections
Cooling method: Water cooling or forced air cooling
Manufacturer ABB Switzerland Ltd

3、 Application scenarios
1. High voltage frequency converters (HV VFDs)
Applied to large motor control systems, such as medium voltage frequency converters in mines, cement plants, and petrochemical industries;

Plays the role of rectification and commutation in the input rectification stage or output inverter section.

2. Electric power transmission system
Used for controlling high-power synchronous/asynchronous motors in various industrial transmission systems;

Widely used in metallurgical rolling mills, power plant boiler blowers, and other occasions.

3. High Voltage Direct Current Transmission System (HVDC)
In HVDC converter stations, thyristor modules are used to construct converter valves to achieve rectification and inversion of high-voltage electrical energy;

Suitable for power grid applications with extremely high stability requirements.

4. Active filtering devices (FACTS)
As an important component of dynamic reactive power compensation and harmonic control in the power grid;

Integrate with ABB control system to achieve rapid response.

5. High power rectifier device
Applied to industrial power sources such as steelmaking electric furnaces and induction heating furnaces;

Realize stable conversion of electrical energy from AC to DC, with high current tolerance capability.

Product details picture:
