6151NB10700 interface chassis module

Model:6151NB10700
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

6151NB10700 interface chassis module

Product manual:

Model: 6151NB10700
Type: Interface chassis/module chassis

core positioning

6151NB10700 is an interface chassis module used for ABB Taylor MOD 300 control system. Its main function is to provide installation platform and backplane connection for multiple interface modules, realizing electrical interconnection and power supply support between modules. It does not handle signals or logic functions on its own, but provides support and channels for various interface modules in the system.

Main functions

Mechanical support: Provide a chassis structure for fixing and inserting interface modules.

Electrical connection: Connect each module to the system bus and power supply through the internal backplane.

Power supply support: Adapt to the power environment of the system, commonly using 117V AC to provide power for the interface module.

Usage scenarios

Installed inside the industrial control cabinet as part of the system framework.

Multiple interface modules and communication modules can be inserted to achieve interconnection between different modules.

Collaborate with CPU modules, I/O modules, power modules, etc. to form a complete control system.

Characteristics and Precautions

It does not have independent functions and is the basic component of modular control systems.

The backplane design ensures electrical interconnection and signal transmission between modules.

During installation, attention should be paid to power matching and cabinet ventilation to ensure stable system operation.
