A-B 1756-EWEB/B Ethernet module

Brand:A-B
Model:1756-EWEB/B
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

A-B 1756-EWEB/B Ethernet module

Product manual:

The A-B 1756-EWEB/B Ethernet module is an Ethernet communication module in the Allen Bradley (Rockwell Automation) ControlLogix series, mainly used in industrial automation systems to achieve data communication between ControlLogix controllers and Ethernet networks.

1、 Product Overview
Model: 1756-EWEB/B

Brand: Allen Bradley (Rockwell Automation)

Series: ControlLogix I/O System

Function: Provide Ethernet interface to enable communication between ControlLogix controller and Ethernet devices (such as upper computer, HMI, other controllers)

2、 Main functions
Supports standard Ethernet communication protocols, including EtherNet/IP

Support web server functionality, allowing remote access to module status and diagnostic information through a web browser

Supports multiple network functions, such as DHCP, BOOTP, and fixed IP address configuration

Rich diagnostic functions, convenient for troubleshooting and network maintenance

Can serve as a communication bridge for ControlLogix systems, connecting industrial networks such as Ethernet and ControlNet

3、 Technical specifications
Communication port: 10/100 Mbps adaptive Ethernet port

Protocol support: EtherNet/IP, TCP/IP, UDP/IP, ICMP, HTTP

Power supply: Powered through the ControlLogix backplane

Interface: RJ-45 Ethernet interface

Installation method: Installed in the ControlLogix rack and used in parallel with other modules

Diagnostic indicator light: Status indicator light displays module operation, network connection, and fault status
