AB 1747-L543/C processor unit

Brand:AB
Model:1747-L543/C
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

AB 1747-L543/C processor unit

Product manual:

1、 Basic Information
Product brand: Allen Bradley (A-B, Rockwell Automation)

Product model: 1747-L543/C

1747-L543: Refers to SLC 5/04 series processors (CPU modules)

/C: Indicates hardware version C, usually involving hardware revisions and certain functional extensions

Type: Central Processing Unit (CPU Processor Unit)

Platform: SLC 5/04- using DH+(Data Highway Plus) communication interface

2、 Main technical specifications
Detailed description of parameter categories
Storage capacity: Program storage: 64K bytes (maximum)
Data storage: 4096 integer data files
Communication port 1 DH+communication port (34 pin circular connector)
1 RS-232 serial port (9-pin D-sub)
Processing speed instruction execution speed is about 0.9 microseconds per instruction
I/O support supports up to 4096 local or remote I/O points
Memory type: battery backup RAM, with EEPROM slot for non-volatile storage
Real time clock integrated real-time clock (can be used for timestamp or scheduling tasks)
Programming software RSLogix 500 (configuration, monitoring, uploading/downloading programs)
Installation method: Installed in SLC 500 series rack (1746 base plate)

3、 Main functions
Centralized logic processing for small and medium-sized control systems

Can communicate with other PLCs, HMIs or upper computers through DH+network

Supports multiple instruction sets: logic control, counting, timing, PID, etc

Can be used in conjunction with remote I/O, analog modules, communication modules, etc

Support hot backup battery replacement and power-off data retention

4、 Typical application scenarios
Factory automation control system

packaging production line

Control of sheet metal processing equipment

Logic processing core in electrical control cabinet

Medium sized process control systems (such as food, beverage, building materials, and other industries)
