ABB 3BHE05904R002 GBU72 control cabinet

Brand:ABB
Model: 3BHE055094R0002 GBU72
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

ABB 3BHE05904R002 GBU72 control cabinet

Product manual:

ABB 3BHE05904R002 (GBU72) control cabinet is a part of ABB's industrial automation system,
Usually used for power and control distribution in large frequency converters, drive systems, and motor control units (such as ACS series or DCS series).
This control cabinet integrates multiple control modules, interfaces, communication devices, and power supply units,
Used to achieve precise control and monitoring of equipment.

GBU72 "is the functional code for this control cabinet, belonging to ABB's GBU (Gate Board Unit) series,
Gate Unit or control interface cabinet commonly used in medium and high voltage drive systems.

Technical parameters (reference specifications, specific models may vary)
Parameter Category Technical Description
Product model 3BHE05904R002 (GBU72)
Product Type: Control Cabinet/Door Pole Drive Control Unit
Installation method: Control cabinet floor mounted or cabinet embedded installation
Communication interface fiber optic, RS-485, CAN, Profibus, etc. (by model)
Function supports power electronic module control, gate signal processing, feedback monitoring
The power supply is usually a DC24V control power supply (depending on the internal module)
Industrial environment, protection level IP20 or above

application area
MV Drives (Medium and High Voltage Variable Voltage Drive System)

Used as a gate drive module or auxiliary control unit for medium voltage frequency converters
(such as ABB ACS6000, DCS6000) system.

Control the on/off of power devices such as IGBT/GTO to achieve high reliability motor control.

Large industrial motor control system

Used for control signal processing, fault detection, and communication interface in high-power motor drive systems.

The main drive system applied to heavy industries such as steel, petrochemicals, cement, and mining.

Power Electronic System

Applied in rectifier and inverter control modules, providing gate signals and system status feedback for power devices.

Power generation and transmission distribution system

Cooperate with high-voltage power quality control equipment to perform power compensation, reactive power regulation, and equipment protection functions.
