AEG Modicon 170BDM34600 Input/Output Module

Brand:AEG MODICON
Model:170BDM34600
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

AEG MODICON 170BDM34600 Input/Output Module

Product manual:

AEG Modicon 170BDM34600 Input/Output Module - Module Description

The 170BDM34600 is a composite module in the AEG/Modicon distributed I/O series, which integrates input and output functions into the same unit and can simultaneously collect field signals and drive actuators. Its design core lies in "compactness, stability, and high compatibility", often used in systems with limited space or requirements for simplified wiring.

Core functions of the module
1. Synchronize the processing of input and output signals

The module has both digital input channels and digital output channels, which can receive on-site status and directly issue action commands to the equipment. It is a typical bidirectional control unit.

2. As an interface between on-site equipment and controllers

By communicating with the PLC master station through the system bus, real-time input data is transmitted and control instructions are received, achieving a complete closed-loop signal link.

3. Support distributed control architecture

Commonly used on remote I/O stations or modular devices to enable control systems to cover a larger field area without the need for long-distance wiring.

Module Features (Enhanced Version)

1. Integrated input/output design
Reduce the number of modules, reduce the space occupied by cabinets, make wiring more compact, and be more suitable for small or dense control cabinets.

2. Channel isolation protection
I/O channels typically have electrical isolation to effectively reduce the risk of damage caused by interference and circuit surges.

3. Corresponding speed stability
The input sampling and output refresh rhythm are consistent, which can meet the synchronous action requirements and is suitable for beat control or interlocking systems.

4. Industrial grade anti-interference capability
Suitable for harsh on-site environments such as high electromagnetic noise and vibration, ensuring stable signals and reliable actions.
