AEG Modicon 3185996 Central Controller Module

Brand:AEG MODICON
Model:3185996
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

AEG MODICON 3185996 Central Controller Module

Product manual:

AEG Modicon 3185996 Central Controller Module - Function and Feature Description

This central controller module belongs to the core unit of the AEG/Modicon old generation control system,
Equivalent to the brain of the entire PLC architecture, responsible for processing logic programs, coordinating I/O, managing data, and communicating with peripheral modules.
Its design concept leans towards industrial grade reliability, emphasizing long-term stable operation and adaptability to the on-site environment.

Main responsibilities and system functions

Execute user logic program
Responsible for cyclically scanning the entire control process, including typical PLC functions such as condition judgment, sequence control, timer/counter, etc.

Manage all I/O modules
Maintain high-speed interaction with input, output, analog, and communication modules through the backplane bus,
Ensure timely data updates and accurate instruction issuance.

Unified System Resource Scheduling
It includes basic management functions such as task management, memory allocation, diagnostic monitoring, and fault detection, and is the stable core of the entire system.

Provide communication and data pathways
According to the system configuration, it supports data exchange with peripheral devices or upper level monitoring systems.

Module Features (Extended Version)

1. Stability first design
Internally adopting electronic design that adapts to a wide range of environments,
Can maintain stable scanning in industrial sites with high temperature differences and electromagnetic interference.

2. High program storage security
Most controllers in the same series have power outage maintenance and data protection mechanisms,
Can maintain the logic program without loss for a long time, suitable for critical process lines.

3. Controllable scanning cycle
The number of epidemic points and program complexity vary, but the CPU can maintain a stable cyclic scanning rhythm;
Fast logic and sequential control are particularly crucial.

4. Complete system diagnostic capability
Provide diagnostic information such as module status, error codes, and communication faults to facilitate quick on-site problem localization and reduce downtime.
