AEG MODICON 6728-042.24467 output module

Product manual:

**AEG Modicon 6728-042.24467

Output Module - Function and Feature Description**

6728-042.24467 belongs to the AEG/Modicon series of digital output modules, whose main function is to convert PLC logic instructions into field drivable execution signals. It is a typical execution unit in the rack, used to control devices such as relays, contactors, solenoid valves, indicator lights, etc.

1. Digital output function

The module provides independent output channels, each of which can independently control external devices:

DC/AC output (depending on specific configuration)

Drive relays, contactors, indicator lights

Suitable for sequential control, action execution, and interlocking operations

Enable PLC logic signals to directly drive on-site equipment.

2. Independent isolation and protection design

Each output is designed with isolation and protection measures:

short circuit protection

overload protection

Strong anti-interference ability

Ensure that on-site load or signal abnormalities do not affect the normal operation of other channels.

3. Industrial environment tolerance

The module can adapt to complex on-site conditions:

Electromagnetic Interference Resistance

Adapt to temperature fluctuations

Anti mechanical vibration

Stable long-distance wiring

Suitable for continuous operation environments such as power, chemical, metallurgical, and mechanical industries.

4. Compatible with the main processor and rack

The output module can be directly mounted on the corresponding rack and work in conjunction with the CPU, input module, and communication module

CPU issues action commands

Output module executes on-site actions

The status information can be transmitted back to the CPU for monitoring

Clear architecture, easy to debug and maintain.

AEG MODICON 6728-042.24467  Product details picture:

6728-042.24467

AEG MODICON 6728-042.24467 product video
