AEG MODICON 7628-04.20059 Input/Output Module

Product manual:

I/O Module - Function and Characteristics Description**

7628-04.20059 belongs to the AEG/Modicon series of general-purpose I/O modules, which can simultaneously process digital inputs and outputs. In the control system, it mainly undertakes the dual functions of collecting field signals and driving actuators. It is a very typical module type in old industrial control systems, suitable for use in small and medium-sized control racks.

1. Integration of input and output functions

Modules can simultaneously handle:

Digital Input (DI) - Collecting switch values, limit switches, and sensor status

Digital output (DO) - driving relays, solenoid valves, indicator lights, contactors

Integrated I/O design makes rack wiring simpler and reduces space occupation.

2. Points and channels are independent

Each input/output is independent and supports:

Dry contact input or DC level input

DC/AC output (depending on specific model configuration)

Independent isolation ensures that each signal does not interfere with each other and is stable and reliable.

3. Strong adaptability to industrial environments

The module is designed for complex on-site environments and features include:

Strong ability to resist electromagnetic interference

Capable of withstanding temperature fluctuations and vibrations

Long distance wiring can still work stably

Especially suitable for continuous operation systems such as electricity, machinery, and chemical engineering.

4. Compatible with the main processor

The module can be directly mounted on the corresponding rack and work together with the CPU and communication module to complete control tasks:

CPU reads input status

Execute output action

Data can be transmitted to the upper system or remote I/O

Clear architecture, easy to debug and maintain.

AEG MODICON 7628-04.20059  Product details picture:

7628-042.20059
