AEG MODICON 7628-042.244 Backboard

Brand:AEG MODICON
Model:7628‑042.244
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

AEG MODICON 7628-042.244 Backboard

Product manual:

Introduction to 7628-042.244 Backplane Module

7628-042.244 is the backplane module (Backplane/Rack Bus) of the AEG/Modicon series PLC system. It is used to connect the central processing unit (CPU), input/output modules, power modules, etc. in PLC systems, to achieve communication and data transmission between modules, and is the core interconnect component of PLC systems.

Core functions and features
● Module interconnection

The backplane provides a unified electrical interface and bus to reliably connect CPUs, I/O modules, power modules, and other components.

By transmitting digital signals, analog signals, and control signals through the backplane bus, data exchange between various modules within the system is achieved.

● System Expansion

Supports the insertion of multiple Modicon series modules, and can add input, output, or function expansion modules as needed.

Modular design facilitates on-site maintenance and upgrades.

● Power and signal management

The backplane provides a unified power interface to ensure stable operation of the CPU and various modules.

Optimization of internal signal circuit design to ensure stable data transmission and reduce interference risks.

● Industrial environment adaptability

Designed to be sturdy and adaptable to industrial site environments, including temperature changes, vibrations, and electrical noise.

Improve the reliability and long-term stability of the system.

Typical application scenarios

Module Interconnection and Communication Center of Industrial Automation PLC System

Connect the central processing unit with digital/analog input/output modules to build a complete control system
