AEG Modicon 7628-042.44800 slot board

Brand:AEG MODICON
Model:7628-042.244800
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

AEG MODICON 7628-042.44800 slot board

Product manual:

AEG Modicon 7628-042.44800 slot board
Product Description

1、 Product positioning
7628-04.244800 belongs to the Backplane/Slot Board used in AEG Modicon control system, mainly used to provide electrical connection channels and signal buses for various functional modules, and is one of the basic structures for the operation of the entire PLC or control system.

2、 Core role

Provide standardized slot positions for controller CPUs, I/O modules, power modules, etc.

Complete the internal power distribution of the system to ensure stable power supply for all modules.

Establish a unified system bus responsible for transmitting data, addresses, and control signals between modules.

Ensure communication synchronization and data refresh between modules.

Provide a structural foundation for expanding rack or multi module systems.

3、 Product Features

Industrial grade reliability design, suitable for long-term installation and stable operation in control cabinets.

The layout of the connectors is neat and compatible with the corresponding Modicon module series.

The board material is resistant to high temperature and humidity, suitable for various working conditions and environments.

Clear signal path reduces communication interference between modules.

Easy to install and maintain, suitable for maintaining and replacing old systems.
