AEG MODICON AS-B805-016 Output Module

Brand:AEG MODICON
Model:AS-B805-016
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

AEG MODICON AS-B805-016 Output Module

Product manual:

This is a digital output module for Modicon 800 series programmable control systems, responsible for converting the logic signals of the controller into electrical signals recognizable by the executing device, widely used in the field of industrial automation control.

Product Features:

Rich output channels: Provides 16 point digital output, which can be connected to relay coils, signal lights, solenoid valves and other execution devices.

Output type: Supports transistor or relay output mode, suitable for various load forms.

Electrical isolation: Each output has a photoelectric isolation design to improve the system's anti-interference ability and safety.

Status display: The module front panel is equipped with LED indicator lights, which display the real-time working status of each output point for easy monitoring and maintenance.

Modular structure: adopting a standard slot structure for easy installation, replacement, and system expansion.

High reliability: Industrial grade design, capable of stable operation in high temperature, humidity, or electromagnetic interference environments.

Communication compatibility: Fully compatible with Modicon main control CPU module and bus system, supporting high-speed data exchange.

Technical parameter summary:

Model: AS-B805-016

Output points: 16 digital output points

Output voltage: DC 24V (typical)

Maximum output current per point: 0.5A

Electrical isolation: optoelectronic isolation design

Status indicator: LED status light at each point

Installation method: Plug in module, compatible with 800 series rack

Working temperature: 0-60 ℃
