AEG MODICON AS-BADU-206 Analysis Input Module

Product manual:

Introduction to AEG Modicon AS-BADU-206 Analysis Input Module
AS-BADU-206 is an analysis input module of the AEG Modicon series,
Mainly used to collect analog signals from on-site equipment and transmit them to the controller,
Realize precise monitoring and control of industrial processes.
It is capable of processing various types of sensor signals, including voltage, current, and thermocouple signals,
Widely used in process control, data acquisition, and process automation.

functional positioning

Collect simulated signals from on-site sensors, such as temperature, pressure, flow rate, or liquid level.

Convert analog signals into digital signals that can be processed by the controller to achieve closed-loop control or monitoring.

Support signal filtering and conditioning to improve measurement accuracy and system stability.

Collaborate with Modicon series controllers and other I/O modules to achieve a complete automation control solution.

Technical Features

Multi channel input design, capable of simultaneously collecting multiple analog signals.

Built in signal isolation and anti-interference functions improve reliability in industrial environments.

Supports multiple input signal types, compatible with voltage, current, and thermocouple measurements.

High precision sampling and fast response ensure the accuracy of real-time monitoring and control.

Industrial grade design, resistant to vibration and dust, suitable for harsh industrial environments.

Structure and usage characteristics

Modular card insertion design, easy to install in Modicon control racks or cabinets.

The wiring terminals are clear and convenient for on-site wiring and maintenance.

The LED status indicator light displays the channel operation status and fault alarm information.

The module is compact and can be installed in combination with other I/O modules to achieve system expansion.

AEG MODICON AS-BADU-206 Product details picture:

AS-BADU-206

AEG MODICON AS-BADU-206 product video
