AEG MODICON AS-BALU-201L CPU Control Module

Product manual:

AEG MODICON AS-BALU-201L CPU Control Module

AS-BALU-201L is the core CPU control module in the Modicon series, responsible for the logical execution, data management, and device coordination of the entire control system.

Main functions

Logic program execution
Scan and process according to the control logic written by the user, achieving functions such as sequential control, conditional judgment, and timed counting.

System scheduling and management
Schedule the I/O scanning cycle, task flow, communication updates, etc. to ensure that the system operates at a consistent pace.

Data processing and caching
Continuously interact with input and output modules, and perform operations, comparisons, and logical processing on collected data.

Backplane communication control
As the core node of the backplane bus, it coordinates the information coordination between various modules to maintain consistency and stability of the system.

System monitoring and self checking
Equipped with basic self checking function, it can detect module abnormalities and provide status reminders for easy maintenance.

Structure and Performance Characteristics

Using industrial grade processing chips, it can maintain stable operation in harsh environments.

Stable scanning cycle, suitable for complex processes or multi-point data processing scenarios.

The program, parameters, and running data all support reliable storage within the module.

Compatible with Modicon 800/984 series structure, it can be directly used for replacing and expanding old systems.

Strong anti-interference ability, supports long-term continuous operation, and has low sensitivity to electromagnetic noise.

The slot installation method is convenient for maintenance and replacement.

Applicable industries and typical applications

Old style DCS/PLC control system

Control of power plant boilers, turbines, and auxiliary equipment

Sequential Control and Safety Logic of Chemical Production Lines

Continuous process control systems for cement, steel, glass, and other materials

Coordination and scheduling of water treatment and environmental protection equipment

Upgrading, Point Expansion, and Life Extension Projects for Old Modicon Systems

AEG MODICON AS-BALU-201L Product details picture:

AS-BALU-201L

AEG MODICON AS-BALU-201L product video
