AEG MODICON AS-BMOT-202 motion module

Product manual:

Introduction to AEG Modicon AS-BMOT-202 Motion Module
AS-BMOT-202 is a module designed specifically for motion control in the AEG Modicon series,
Mainly used for precise position, speed, and acceleration control of servo motors, stepper motors, or other actuators.

functional positioning

Accurate control of on-site motion actuators, including start, stop, speed adjustment, and position control.

Support multi axis or single axis synchronous motion to achieve coordinated execution of complex actions.

Receive instructions from the main controller or operation panel, convert logic signals into drive signals for output.

It can be linked with other I/O modules or controllers to achieve complete process automation control.

Technical Features

Provide high-precision PWM or pulse signal output, compatible with various servo and stepper drivers.

Support closed-loop and open-loop control modes to ensure stability and response speed of motion.

Built in motion control logic and error monitoring functions, such as overload, limit protection, and alarm signal output.

Compatible with Modicon series controllers, it can seamlessly integrate into existing automation systems.

Structure and usage characteristics

The module adopts a standard card insertion design, which facilitates installation and disassembly in the control cabinet.

The output port layout is clear, making it easy to connect and maintain on site.

The status indicator light displays the operating status and alarm information of the motion channel for easy debugging.

Industrial grade design, strong anti vibration and anti-interference capabilities, suitable for complex industrial environments.

Typical application scenarios

Motion control of automated robotic arms and conveyor mechanisms.

Precise positioning and speed adjustment of packaging, sorting, and assembly lines.

Scenarios in industrial production equipment that require multi axis synchronization or sequential action.

Motion control expansion or old equipment upgrade and renovation project for Modicon system.

AEG MODICON AS-BMOT-202  Product details picture:

AS-BMOT-202

AEG MODICON AS-BMOT-202  product video
