AEG MODICON AS-HDTA-200 main and secondary rack slots

Brand:AEG MODICON
Model:AS-HDTA-200
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

AEG MODICON AS-HDTA-200 main and secondary rack slots

Product manual:

AS-HDTA-200 is a slot module used in the Modicon series system for main and auxiliary control racks or expansion racks. Its main function is to provide standardized installation interfaces for CPU, I/O modules, and communication modules, and ensure stable and reliable data and power connections between main and auxiliary racks or expansion racks.

Main functions

Module installation and fixation
Provide standardized slots for safe and secure installation of various modules in the rack.

Main and auxiliary frame communication bridge
Ensure data synchronization and stable communication between the main control rack and the auxiliary control rack, and achieve dual machine redundancy or distributed control.

Extended support
Can be used to connect to remote or expansion racks, providing interfaces for increasing I/O points or functional modules in the system.

Power distribution and signal transmission
Complete power and communication signal distribution through the backplane, providing a unified interface for each module.

Structure and Characteristics

Industrial grade design, strong seismic and anti-interference capabilities, suitable for continuous operation environment.

The slot layout is clear and supports compatible installation of multiple Modicon CPUs, I/O, and communication modules.

The backplane communication line has been optimized to ensure real-time and reliable data transmission.

Flexible connections between racks facilitate system expansion or module replacement.

Can support dual machine configuration of main control rack and auxiliary control rack, achieving redundancy or backup function.

Typical application scenarios

Installation of main and auxiliary control frames in the automation control cabinet of large factories

Rack Expansion and Redundant Configuration of Distributed Control Systems

Continuous production control stations for industries such as chemical, power, metallurgy, and steel

System expansion or maintenance project for outdated Modicon platform

Control scenarios that require modular installation and dual machine redundancy
