AEG MODICON ASP890300 Communication Module

Brand:AEG MODICON
Model:ASP890300
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

AEG MODICON ASP890300 Communication Module

Product manual:

This is a remote I/O communication module for Modicon 800 series systems, belonging to high-performance data transmission and interface units,
Capable of achieving high-speed and stable communication between the main controller and remote I/O racks.

Product Features:

Strong remote communication capability: using coaxial cable communication method, supporting long-distance data transmission, with a communication rate of about 1.544 MHz.

High speed data processing: The I/O scanning speed is fast, and the response time is less than 5 milliseconds under 256 point input-output conditions.

Flexible power supply: Supports AC 115V/230V or 24V DC input, providing stable power for modules and I/O devices.

Multi output capability: capable of outputting+5.0VDC,+4.3VDC, and -5.0VDC, with different voltage outputs to meet the power supply needs of various types of I/O modules.

Dual channel communication design: supports primary and backup communication lines to improve system reliability and anti-interference capability.

Strong compatibility: Suitable for 800 series rack systems such as H810-208, H819-209, H827-209, etc., and backward compatible with some old model modules.

Indication and diagnostic function: equipped with status indicator lights, such as power status, communication activity, error status, etc., for easy fault detection.

Technical parameter summary:

Model: ASP890300 (also known as AS-P890-300)

Type: Remote I/O Communication Module

Communication medium: 75 ohm coaxial cable

Communication speed: 1.544 MHz

Input power supply: AC 115V/230V or 24V DC

Output power supply:+5VDC 7A,+4.3VDC 6A, -5VDC 0.5A (total output of+5V and+4.3V does not exceed 7A)

Status display: PWR OK, READY, COMM ACTION, COMM ERROR

Installation method: Rack mounted (Modicon 800 series compatible slot rack)

Status: Discontinued

Application fields:
This communication module is widely used in industrial automation systems for high-speed data transmission between PLCs and remote I/O modules.
Commonly used in power, chemical, metallurgical, production line automation and other fields to achieve distributed control and signal transmission.
